RoadForce

The highest efficacy with long lasting reliability.

Popular downloads

View all downloads

Where to buy

Products

Product				Compare
BRP481 LED73-2S NW 41W DML P7 0-10 919306034291 41 W, Grey	178	7300	4000	Product leaflet PDF Where to buy
BRP481 LED73-2S NW 41W DWL P7 0-10 M 919306034321 41 W, Grey	178	7300	4000	Product leaflet PDF Where to buy
BRP481 LED84/NW 54W II DWL PSR P7 EXP 919306035751 LED-HP \| LED High Power, 55.8 W, Gray	150	8340	4000	Product leaflet PDF Where to buy
BRP482 LED136-2S NW 76W DML P7 0-10 919306034651 76 W, Grey	178	13600	4000	Product leaflet PDF Where to buy
BRP482 LED104-2S NW 56W DML P7 0-10 919306034471 56 W, Grey	186	10400	4000	Product leaflet PDF Where to buy
BRP482 LED160-2S NW 92W DWL P7 0-10 M 919306034801 92 W, Grey	174	16000	4000	Product leaflet PDF Where to buy
BRP482 LED126-2S NW 70W DWL P7 0-10 M 919306034621 70 W, Grey	180	12600	4000	Product leaflet PDF Where to buy
BRP486 LED351-2S NW 195W DML P7 0-10 M 919306035561 195 W, Grey	180	35100	4000	Product leaflet PDF Where to buy

143 items

of 18

Products per page

Description

With an extremely high measured efficacy of up to 190 lm/W, excellent optical gear and great installation flexibility with an integrated angle adjustment system, the RoadForce family ensures a high-quality luminous result compliant with local application standards. Designed with robust components, the RoadForce luminaire complies with the highest quality standards while reducing the maintenance costs.

Benefits

Presenting great optical performance and high measured efficacy (of up to 190 lm/W) combined with its installation versatility, with an embedded tilt angle adjustment system (-5° / 0° / +5°), RoadForce achieves energy savings of 70% versus conventional lighting alternatives, with an additional savings potential when combined with control and tele management systems (Interact City).
The broadest and most diverse product family in its category, with 24 lumen output options, allowing for the optimisation of lighting projects according to their actual specifications.
Achieve maintenance cost reductions: RoadForce incorporates long lasting LED technologies and other high-quality components ensuring a system lifetime of 78.000 hours (@L70B50) at 35 ºC.

Features

Die cast aluminium body, Grey Munsel N6.5 painting with high resistance to corrosion, tested for 1.000 hours salt spray and sealing with silicon gasket.
Two colour temperature options available (4000K and 5000K) and two light distribution options available (DML and DWL).
Standard surge protection: 10kV/10kA. Optional version available: 10kV/12kA.
CISPR15 compliant dimmable driver.
High transparency UV resistant polycarbonate (PC) lenses.
Easy connection to tele management systems such as Interact City, with a standard 7-pin NEMA socket, allowing for remote lighting management.

Applications

Traffic routes: highways, streets, and avenues., Urban areas: parks and plazas, pedestrian crossings, bike paths, parking areas., Large open areas: industrial yards, harbours, airports, canals, railway terminals.
