Philips lighting
Global

Products

Product Compare
BRP490L LED181/NW 120W DW2n PSA SP1
BRP490L LED181/NW 120W DW2n PSA SP1
911401647209
151
18100
4000
Product leaflet PDF
Where to buy
BRP490 LED47/WW 30W DW2n PSA SP1 P5
BRP490 LED47/WW 30W DW2n PSA SP1 P5
911401648509
148
4700
3000
Product leaflet PDF
Where to buy
BRP490L LED153/WW 100W DW2n PSA SP1 P5
BRP490L LED153/WW 100W DW2n PSA SP1 P5
911401648109
150
15300
3000
Product leaflet PDF
Where to buy
BRP490 LED48/NW 30W DW2n PSA
BRP490 LED48/NW 30W DW2n PSA
911401647709
153
4800
4000
Product leaflet PDF
Where to buy
BRP490 LED75/NW 50W DW2n PSA
BRP490 LED75/NW 50W DW2n PSA
911401647609
151
7500
4000
Product leaflet PDF
Where to buy
BRP490L LED124/NW 80W DW2n PSA SP1
BRP490L LED124/NW 80W DW2n PSA SP1
911401647409
155
12400
4000
Product leaflet PDF
Where to buy
BRP490L LED120/WW 80W DW2n PSA SP1 P5
BRP490L LED120/WW 80W DW2n PSA SP1 P5
911401648209
150
12000
3000
Product leaflet PDF
Where to buy
BRP490L LED181/NW 120W DW2n PSA SP1 P5
BRP490L LED181/NW 120W DW2n PSA SP1 P5
911401647809
151
18100
4000
Product leaflet PDF
Where to buy

Product family information

Description

RoadFlair ECO is a newly designed road lighting product, set to meet customers’ requirements, including high lumen efficacy for energy saving and sustainability, aesthetic design for nice shape and appearance, quality material and components for product reliability and long lifetime, professional optic for lighting application fulfilment, dimming and system control interface for improving municipal operations and offering future-proof features. RoadFlair ECO’s competitive price would help on the acceleration of road lighting LED transformation, to more sustainable society and smarter city.

Benefits

  • High lumen efficacy for energy saving

  • Robust quality and reliability

  • Professional optic for various road applications

Features

  • Two housing types covering up to 18Klm

  • Typical 150lm/W, high lumen efficacy for energy saving

  • Robust quality and reliability, 100Khrs lifetime

Applications

Pedestrian Road, Residential Road, Interchange, Highway Road

Specifications

  • Material
    Housing: die-cast aluminium Optic cover: polycarbonate
  • Light Source
    5050 LED
  • Installation
    Side entry 40-60mm Optional adjustable spigot
  • Luminous flux
    System flux up to 18100lm
  • Correlated color temperature - CCT
    5700K 4000K 3000K 2700K 2200K
  • Luminaire efficacy
    4000K: 150lm/W
  • Color Rendering index - CRI
    70
  • Power
    up to 120W
  • Mains Voltage
    220-240V / 50-60Hz
  • Control system input
    1-10V
  • Dimming
    PSA: 1-10V, AOC
  • Operating Temperature range
    -40 to +50C Ta
  • Ingress protection
    IP66
  • Certification
    IECEE CB, CE, CQC
