CoreLine trunking gen2.5

Innovative LED light lines have never been so simple

Popular downloads

View all downloads

Where to buy

Products

Product				Compare
CoreLine trunking gen2.5, Basic (stand alone) version, 80 W, L3400 mm, 16000 lm, 4000 K, DALI, Narrow beam, Frosted, White, IP20 LL243X 160S/840 UE DIA NB BV WH 910925870149 Basic (stand alone) version, L3400 mm, Steel, White, Traffic white (RAL9016), Dali dimming Interact System ready, 16000 lm, 80 W, 200 lm/W, 4000 K, (0.38, 0.38) SDCM <3, Narrow beam, Frosted, Polycarbonate, IP20 \| Finger-protected, IK02 \| 0.2 J standard, Safety class I, Push-in connector 5-pole	200	16000	4000	Product leaflet PDF IES files IES Configure product Where to buy
CoreLine trunking gen2.5, 45 W, L3400 mm, 9000 lm, 4000 K, Wide beam, Frosted, White, IP20 LL243X 90S/840 UE PSU WB 5x1.5 WH 910925870133 L3400 mm, Steel, White, Traffic white (RAL9016), Power supply unit (On/Off), 9000 lm, 45 W, 200 lm/W, 4000 K, (0.38, 0.38) SDCM <3, Wide beam, Frosted, Polycarbonate, IP20 \| Finger-protected, IK02 \| 0.2 J standard, Safety class I, Connection unit 5-pole	200	9000	4000	Product leaflet PDF IES files IES Configure product Where to buy
CoreLine trunking gen2.5, 80 W, L3400 mm, 16000 lm, 4000 K, DALI, Narrow beam, Frosted, White, IP20 LL243X 160S/840 UE DIA NB 7x1.5 WH 910925870138 L3400 mm, Steel, White, Traffic white (RAL9016), Dali dimming Interact System ready, 16000 lm, 80 W, 200 lm/W, 4000 K, (0.38, 0.38) SDCM <3, Narrow beam, Frosted, Polycarbonate, IP20 \| Finger-protected, IK02 \| 0.2 J standard, Safety class I, Connection unit 7-pole	200	16000	4000	Product leaflet PDF IES files IES Configure product Where to buy
CoreLine trunking gen2.5, 128 W, L3400 mm, 22500 lm, 4000 K, DALI, Opal, Opal, White, IP20 LL243X 240S/840 HE DIA O 7x1.5 WH 910925870144 L3400 mm, Steel, White, Traffic white (RAL9016), Dali dimming Interact System ready, 22500 lm, 128 W, 176 lm/W, 4000 K, (0.38, 0.38) SDCM <3, Opal, Opal, Polycarbonate, IP20 \| Finger-protected, IK02 \| 0.2 J standard, Safety class I, Connection unit 7-pole	176	22500	4000	Product leaflet PDF IES files IES Configure product Where to buy
910925870135 LL243X \| Coreline trunking Gen2.5, 82 W, Power supply unit (On/Off), Wide beam, 84° x 84°	195	16000	4000	Product leaflet PDF IES files IES Configure product Where to buy
CoreLine trunking gen2.5, 65 W, L1700 mm, 12000 lm, 4000 K, DALI, Wide beam, Frosted, White, IP20 LL242X 120S/840 UE DIA WB 7x1.5 WH 910925870127 L1700 mm, Steel, White, Traffic white (RAL9016), Dali dimming Interact System ready, 12000 lm, 65 W, 185 lm/W, 4000 K, (0.38, 0.38) SDCM <3, Wide beam, Frosted, Polycarbonate, IP20 \| Finger-protected, IK02 \| 0.2 J standard, Safety class I, Connection unit 7-pole	185	12000	4000	Product leaflet PDF IES files IES Configure product Where to buy
CoreLine trunking gen2.5, 65 W, L1700 mm, 11000 lm, 4000 K, Opal, Opal, White, IP20 LL242X 120S/840 HE PSU O 5x1.5 WH 910925870130 L1700 mm, Steel, White, Traffic white (RAL9016), Power supply unit (On/Off), 11000 lm, 65 W, 169 lm/W, 4000 K, (0.38, 0.38) SDCM <3, Opal, Opal, Polycarbonate, IP20 \| Finger-protected, IK02 \| 0.2 J standard, Safety class I, Connection unit 5-pole	169	11000	4000	Product leaflet PDF IES files IES Configure product Where to buy
CoreLine trunking gen2.5, Basic (stand alone) version, 82 W, L3400 mm, 16000 lm, 4000 K, Wide beam, Frosted, White, IP20 LL243X 160S/840 UE PSU WB BV WH 910925870146 Basic (stand alone) version, L3400 mm, Steel, White, Traffic white (RAL9016), Power supply unit (On/Off), 16000 lm, 82 W, 195 lm/W, 4000 K, (0.38, 0.38) SDCM <3, Wide beam, Frosted, Polycarbonate, IP20 \| Finger-protected, IK02 \| 0.2 J standard, Safety class I, Push-in connector 3-pole	195	16000	4000	Product leaflet PDF IES files IES Configure product Where to buy

36 items

of 5

Products per page

Description

CoreLine Trunking gen2 is a light-line system that is designed for simplicity. It comes in a choice of lengths, flux packages and beam shapes to suit every project and application. Easy to use and integrate with spots and sensors, CoreLine Trunking gen2 provides consistent, high-quality lighting with added protection against accidental water ingress. The innovative system is also easy to assemble and install for faster retrofits and refurbishments

Benefits

Simplicity – easy to understand architecture
Wide portfolio offer including emergency lighting options
Consistent, high-quality light without color or striping artefacts
Easy to order, fast to assemble and install
InterAct ready for enhanced use in Retail and Industry applications
Fully compliant with relevant norms

Features

Intuitive, single layer architecture – only #2 12NCs needed to create a line
Choice of 3 lengths, each with 3 flux packages
8 different optics with consistent light quality
Dedicated sensor units to upgrade to Interact system propositions
Lumen maintenance @ 50,000 hours - L85
Available as trunking and standalone versions

Applications

Food and Large Retailers, Manufacturing, Warehouses
