    Ledinaire Batten

    Philips Ledinaire batten – For your everyday lighting jobs, easy to choose from the shelve and to install.

    View all 10 products Philips
    More downloads
    Where to buy
    Download family leaflet
    Ledinaire Batten
    Philips

    Ledinaire Batten

    Products
    Downloads
    Specifications
    b2b-li.related-families-title
    b2b-li.accessories.title
    Download family leaflet
    Where to buy
    10 Ledinaire Batten Products found

    Browse the Ledinaire Batten products and find the product that you are looking for by using the compare option.

    Close filters Show filters
    Show more filters
    Show less filters
    • Product
    • Efficacy (lm/W)
    • Luminous flux (lm)
    • CCT (K)
    • IES
    • Leaflet

    Sort by:

        Accessories

        Product family information

        The Ledinaire batten (BN021C) range contains a selection of popular off-the-shelf batten LED luminaires that comes with the high Philips quality levels at a competitive price. Reliable, energy efficient and affordable. Ledinaire enables, simple and flexible installation, with light-line creation possibility.

        Benefits

        Philips quality and reliability
        Energy saving
        Compact design
        Easy and flexible installation, with line connection possibility

        Features

        Light line up to ten battens
        Mounting accessories included
        Available in from 30cm to 1.8m length
        2 CCT: 3000K, 4000K

        Applications

        General lighting
        Storage rooms
        Cove lighting
        Downloads
        Visuals
        Leaflets
        Product family details
        General
        Type
        • BN060C
        Light source
        • Replaceable LED module (LEDtube)
        Power
        • 1 x TLED16: 18 W
        • 2 x TLED16: 36 W
        Beam angle
        • 150º
        Luminous flux
        • 1 x TLED16: 1600 lm
        • 2 x TLED16: 3200 lm
        Correlated Color Temperature
        • 4000 K (Neutral white)
        Lumen maintenance at median useful life* 50000 h
        • L65
        Control gear failure rate at median useful life 50000 h
        • 7.5%
        Performance Ambient Temperature Tq
        • +25 ºC
        Operating temperature range
        • +10 to +40 ºC
        Driver
        • Built-in
        Mains voltage
        • 220-240 V / 50-60 Hz
        Dimming
        • Not dimmable
        Material
        • Housing: aluminum, extruded
        • End caps / lamp holder: polycarbonate
        • Mounting clips: stainless steel (inox301)
        Color
        • White
        Connection
        • Integral male / female connectors
        Maintenance
        • No internal cleaning required
        Installation
        • Individual or in line; clicking the luminaire into pre-screwed ceiling brackets
        • Through-wiring possible
        • Installation without removing lamp and cover
        Accessories
        • Fly-wire power connector included
        • Flexible light line cord included
