  • Cleanroom LED CR250B – uniform, reliable, value-for-money solution

    CR150B LED35S/840 PSD W60L60 IP54
    LED
    CR150B LED35S/840 PSD W60L60 IP54

    CR150B LED35S/840 PSD W60L60 IP54

    Order code: 910503910176

    Full Product Code: 871869607292900

    Downloads

    Leaflet
    Size:61.7 kB

    See all downloads

Specifications Show all

General Information
Number of light sources
2 pcs
Lamp family code
GRN35  [ LED GreenLine 3500 lm]
Light source color
840 neutral white
Light source replaceable
Yes
Number of gear units
1 unit
Driver/power unit/transformer
Power supply unit with DALI interface
Driver included
Yes
Optic type
-
Optical cover/lens type
Polymethyl methacrylate bowl/cover
Luminaire light beam spread
110°
Control interface
DALI
Connection
-
Cable
Cable 0.75 m without plug
Protection class IEC
Safety class II
Glow-wire test
Temperature 650 °C, duration 30 s
Flammability mark
For mounting on easily flammable surfaces
CE mark
CE mark
ENEC mark
-
Warranty period
3 years
Remarks
*-Per Lighting Europe guidance paper “Evaluating performance of LED based luminaires - January 2018”: statistically there is no relevant difference in lumen maintenance between B50 and for example B10. Therefore the median useful life (B50) value also represents the B10 value.
Constant light output
No
Number of products on MCB of 16 A type B
24
RoHS mark
RoHS mark
Operating and Electrical
Input Voltage
220-240 V
Input Frequency
50 to 60 Hz
Power consumption at dimming
3 W
Inrush current
4.6 A
Inrush time
750 ms
Power Factor (Min)
0.9
Controls and Dimming
Dimmable
Yes
Mechanical and Housing
Housing Material
Steel
Reflector material
-
Optic material
-
Optical cover/lens material
Polymethyl methacrylate
Fixation material
-
Optical cover/lens finish
Opal
Overall length
595 mm
Overall width
595 mm
Overall height
86 mm
Length
595 mm
Diameter
-
Approval and Application
Ingress protection code
IP54  [ Dust accumulation-protected, splash-proof]
Mech. impact protection code
IK03  [ 0.3 J]
Initial Performance (IEC Compliant)
Initial luminous flux (system flux)
3500 lm
Luminous flux tolerance
+/-5%
Initial LED luminaire efficacy
88 lm/W
Init. Corr. Color Temperature
4000 K
Init. Color Rendering Index
>80
Initial chromaticity
(0.38, 0.38) SDCM <4
Initial input power
40 W
Power consumption tolerance
+/-5%
Over Time Performance (IEC Compliant)
Control gear failure rate at median useful life 50000 h
5 %
Lumen maintenance at median useful life* 50000 h
L70
Application Conditions
Ambient temperature range
0 to +40 °C
Performance ambient temperature Tq
25 °C
Maximum dim level
1%
Suitable for random switching
Yes (relates to presence/ movement detection and daylight harvesting)
Product Data
Full product code
871869607292900
Order product name
CR150B LED35S/840 PSD W60L60 IP54
EAN/UPC - Product
8718696072929
Order code
910503910176
Numerator - Quantity Per Pack
1
Numerator - Packs per outer box
1
Material Nr. (12NC)
910503910176
Net Weight (Piece)
6.000 kg

Eco passport - Our environmental product specifications overview

Philips cares about the environment and society at large, and strongly supports eco-design of products.

Installation Diagrams
CR150B W60L60
CR150B W60L60
Photometrics
IFGU1_CR150BLED35S840PSDW60L60IP54
IFGU1_CR150BLED35S840PSDW60L60IP54
