| Inrush current | 53
A
|
| Input Voltage | 220 to 240
V
|
| Line Frequency | 50 to 60
Hz
|
| Number of products on MCB of 16 A type B | 8
|
| Power Consumption | 95
W
|
| Connection | 2 Push-in connector 5-pole
|
| Cable | -
|
| Input Frequency | 50 to 60
Hz
|
| Inrush time | 0.3
ms
|
| Power Factor (Fraction) | 0.99
|
| Lumen maintenance at median useful life* 100000 h | L96
|
| Control gear failure rate at median useful life 100000 h | 10
%
|
| EU RoHS compliant | Yes
|
| Surge Protection (Common/Differential) | Luminaire surge protection level until 6 kV differential mode and 8 kV common mode
|
| Flammability mark | For mounting on normally flammable surfaces
|
| Ingress protection code | IP66
[Dust penetration-protected, jet-proof] |
| Protection class IEC | Safety class I
|
| Warranty period | 5 years
|
| Mech. impact protection code | IK08
[5 J vandal-protected] |
| CE mark | Yes
|
| Sustainability rating | -
|
| ENEC mark | ENEC plus mark
|
| EAN/UPC - Case | 8719514079618
|
| Numerator - Quantity Per Pack | 1
|
| Full product name | BGP283 LED160-4S/740 I DM11 D9 48/60S
|
| Full product code | 871951407961800
|
| Order code | 910925866695
|
| Material number (12NC) | 910925866695
|
| Order product name | BGP283 LED160-4S/740 I DM11 D9 48/60S
|
| Numerator - Packs per outer box | 1
|
| Driver/power unit/transformer | Power supply unit with DALI interface
|
| Constant light output | No
|
| Control interface | DALI
|
| Dimmable | Yes
|
| Light source replaceable | Yes
|
| Value ladder | Specification
|
| Light source engine type | LED
|
| Lamp family code | LED160
[LED module 16000 lm] |
| Driver included | Yes
|
| Service tag | Yes
|
| Product family code | BGP283
[UniStreet gen2 Medium] |
| Number of gear units | 1 unit
|
| Remarks | * At extreme ambient temperatures the luminaire might automatically dim down to protect components
|
| Lighting Technology | LED
|
| Reflector material | Polycarbonate
|
| Overall length | 626
mm
|
| Optical cover/lens shape | Flat
|
| Mounting device | Side-entry for diameter 48 to 60 mm
|
| Optic material | Polymethyl methacrylate
|
| Overall width | 340
mm
|
| Effective projected area | 0.0246
m²
|
| Optical cover/lens material | Glass
|
| Dimensions (Height x Width x Depth) | 95 x 340 x 626 mm
|
| Housing Color | Gray
|
| Optical cover/lens finish | Clear
|
| Fixation material | Aluminum
|
| Housing Material | Aluminum die cast
|
| Overall height | 95
mm
|
| Maximum dim level | 0% (digital)
|
| Performance ambient temperature Tq | 25 °C
|
| Initial chromaticity | (0.381, 0.379) SDCM <5
|
| Power consumption tolerance | +/-10%
|
| Luminous flux tolerance | +/-7%
|
| Init. Color Rendering Index Tolerance | +/-2
|
| Ambient temperature range | -40 to +50 °C
|
| Luminous Flux | 14,080
lumen
|
| Standard tilt angle posttop | 0°
|
| Correlated Color Temperature (Nom) | 4000
K
|
| Luminous Efficacy (rated) (Nom) | 148
lm/W
|
| Optic type outdoor | Distribution medium 11
|
| Luminaire light beam spread | 160° - 42° x 54°
|
| Color rendering index (CRI) | 70
|
| Upward light output ratio | 0
|
| Light source color | 740 neutral white
|
| Optical cover/lens type | Flat glass
|
| Standard tilt angle side entry | 0°
|
