| Lamp family code | LED-MD
[ LED Multi-die] |
| Light source color | 740 neutral white
|
| Light source replaceable | No
|
| Number of gear units | 1 unit
|
| Driver/power unit/transformer | Power supply unit regulating with constant light output
|
| Driver included | Yes
|
| Optical cover/lens type | Tempered glass
|
| Luminaire light beam spread | 40°
|
| Control interface | -
|
| Connection | Connection unit 3-pole
|
| Cable | -
|
| Protection class IEC | Safety class II
|
| Flammability mark | -
|
| CE mark | Yes
|
| ENEC mark | -
|
| Warranty period | 5 years
|
| Optic type outdoor | Symmetrical
|
| Constant light output | No
|
| Number of products on MCB of 16 A type B | 1
|
| EU RoHS compliant | Yes
|
| Light source engine type | LED
|
| Serviceability class | Class B, luminaire is equipped with some serviceable parts (when applicable): driver, control units, surge protection device, front cover and mechanical parts
|
| Product family code | BCP608
[ PROFLOOD LED] |
| Upward light output ratio | 0.67
|
| Standard tilt angle posttop | 0°
|
| Standard tilt angle side entry | 0°
|
| Input Voltage | 220/240
V
|
| Input Frequency | 50 or 60
Hz
|
| Inrush current | 43
A
|
| Inrush time | 0.260
ms
|
| Power Factor (Min) | 0.9
|
| Dimmable | No
|
| Housing Material | Aluminum
|
| Reflector material | Glass
|
| Optic material | Glass
|
| Optical cover/lens material | Glass
|
| Fixation material | Steel
|
| Mounting device | Mounting bracket adjustable
|
| Optical cover/lens shape | Curved
|
| Optical cover/lens finish | Clear
|
| Overall length | 674
mm
|
| Overall width | 294
mm
|
| Overall height | 400
mm
|
| Effective projected area | 0.12
m²
|
| Color | Gray
|
| Dimensions (Height x Width x Depth) | 400 x 294 x 674 mm
|
| Ingress protection code | IP65
[ Dust penetration-protected, jet-proof] |
| Mech. impact protection code | IK06
[ 1 J] |
| Surge Protection (Common/Differential) | Luminaire surge protection level until 6 kV differential mode and 10 kV common mode
|
| Sustainability rating | -
|
| Initial luminous flux (system flux) | 5140
lm
|
| Luminous flux tolerance | +/-5%
|
| Initial LED luminaire efficacy | 66
lm/W
|
| Init. Corr. Color Temperature | 4000
K
|
| Init. Color Rendering Index | >70
|
| Initial chromaticity | (0.3818,0.3797) 3-step
|
| Initial input power | 78
W
|
| Power consumption tolerance | +/-5%
|
| Init. Color Rendering Index Tolerance | +/-2
|
| Control gear failure rate at median useful life 50000 h | 5
%
|
| Lumen maintenance at median useful life* 50000 h | L80
|
| Ambient temperature range | -20 to +50 °C
|
| Performance ambient temperature Tq | 25 °C
|
| Maximum dim level | Not applicable
|
| Full product code | 871951420426300
|
| Order product name | BCP608 LED84/740 II EB D9 SHUT GR10714
|
| EAN/UPC - Product | 8719514204263
|
| Order code | 912300057846
|
| Numerator - Quantity Per Pack | 1
|
| Numerator - Packs per outer box | 1
|
| Material Nr. (12NC) | 912300057846
|
| Net Weight (Piece) | 30.500
kg
|
