    • Digital ignitors for maximum reliability

      SI 54 380-415V 50/60Hz
      SI 54 380-415V 50/60Hz

      SI 54 380-415V 50/60Hz

      Order code: 913619149966

      Full Product Code: 871150091548130

      Downloads

      Leaflet
      Size:761.3 kB

      See all downloads

    Specifications Show all

    General Information
    Application Code
    54
    Lamp Type
    HPI
    Number of Lamps
    1 piece/unit
    Operating and Electrical
    Input Voltage
    380 to 415 V
    Input Frequency
    50 to 60 Hz
    Igniton Type
    Parallel
    Number of Ignition Pulses
    1
    Ignition Voltage (Max)
    1.5 kV
    Response Voltage
    330 V
    Mains Voltage Performance (AC)
    -8%-+6%
    Mains Voltage Safety (AC)
    -10%-+10%
    Power Losses (Nom)
    1.0 W
    Wiring
    Cable Capacity Wires Device to Lamp (Nom)
    120 nF
    Wire Striplength
    6.0 mm
    Ballast Contact Wire Cross Section
    0.70-2.50 mm²
    Connector Type
    Screw
    System characteristics
    Rated Ballast-Lamp Power
    2000 W
    Temperature
    T-Ambient (Max)
    75 °C
    T-Ambient (Min)
    -20 °C
    T-Storage (Max)
    80 °C
    T-Storage (Min)
    -25 °C
    T-Case Maximum (Max)
    80 °C
    Mechanical and Housing
    Housing
    SNI-115
    Approval and Application
    Approval Marks
    CE marking
    ENEC certificate
    Product Data
    Full product code
    871150091548130
    Order product name
    SI 54 380-415V 50/60Hz
    EAN/UPC - Product
    8711500915481
    Order code
    913619149966
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    20
    Material Nr. (12NC)
    913619149966
    Net Weight (Piece)
    0.083 kg
    Installation Diagrams
    SI 54 360-415V 50/60Hz
    SI 54 360-415V 50/60Hz
