| Application Code | K302-A2-ITS
|
| Design | BC1-118
|
| Lamp Type | MH
|
| Number of Lamps | 1
piece/unit
|
| Input Voltage | 230
V
|
| Input Frequency | 50
Hz
|
| Power Factor 100% Load (Nom) | 0.85
|
| Mains Voltage Performance (AC) | -8%-+6%
|
| Mains Voltage Safety (AC) | -10%-+10%
|
| Input Current with PF Correction | 0.36
A
|
| Input Current without PF Correction | 0.53
A
|
| Power Factor without PF Compensation (Nom) | 0.35
|
| Power Losses (Nom) | 6
W
|
| Wire Striplength | 6.0
mm
|
| Ballast Contact Wire Cross Section | 2.5
mm²
|
| Connector Type | Screw
|
| Capacitor | 6µF/250V
|
| Rated Ballast-Lamp Power | 35 W
|
| Recommended Ignitor | for SON/CDO/CDM lamps ignitor SKD 578 (913700655366) or series digital SUD40 (913700193591) only CDM
|
| T-Storage (Max) | 130
°C
|
| T-Storage (Min) | -30
°C
|
| T-Winding (Max) | 140
°C
|
| Delta-T Normal Conditions | 35 °C
|
| Active Temperature Protection | Yes
|
|
| Approval Marks | CE marking
|
ENEC certificate
|
| Full product code | 871869674068200
|
| Order product name | BMH 35 K302-A2-ITS 230V 50Hz
|
| EAN/UPC - Product | 8718696740682
|
| Order code | 913700751626
|
| Numerator - Quantity Per Pack | 1
|
| Numerator - Packs per outer box | 6
|
| Material Nr. (12NC) | 913700751626
|
| Net Weight (Piece) | 1.140
kg
|
