    • Simple, robust magnetic ballast

      BHLA 125L 200
      BHLA 125L 200

      BHLA 125L 200

      Order code: 913713018659

      Full Product Code: 872790095590300

      Downloads

      Leaflet
      Size:350.1 kB

      See all downloads

    Specifications Show all

    General Information
    Application Code
    L200
    Operating and Electrical
    Input Voltage
    220 V
    Input Frequency
    50 Hz
    Power Factor 100% Load (Min)
    0.55
    Mains Voltage Performance (AC)
    -8%-+6%
    Mains Voltage Safety (AC)
    -10%-+10%
    Input Current with PF Correction
    1.95 A
    Input Current without PF Correction
    2.18 A
    Power Factor without PF Compensation (Nom)
    0.85
    Power Losses (Nom)
    14.2 W
    Wiring
    Connector Type
    Screw
    System characteristics
    Rated Ballast-Lamp Power
    125 W
    Temperature
    T-Winding (Max)
    130 °C
    Delta-T Normal Conditions
    70 °C
    Approval and Application
    Approval Marks
    CE marking
    CCC certificate
    Product Data
    Full product code
    872790095590300
    Order product name
    BHLA 125L 200
    EAN/UPC - Product
    8711500999863
    Order code
    913713018659
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    6
    Material Nr. (12NC)
    913713018659
    Net Weight (Piece)
    1.250 kg
    Installation Diagrams
    BHLA 125L 200
    BHLA 125L 200
