LED MOD 24W 865

Specifications Show all

Operating and Electrical

Line Frequency	50 to 60 Hz
Lamp Current (Nom)	210 mA
Power Consumption	24 W
Warm-up time to 60% light	0.5 s
Input Frequency	50 to 60 Hz
Voltage (Nom)	220-240 V
Power Factor (Fraction)	0.5
Starting Time (Nom)	0.5 s

Approval and Application

EU RoHS compliant	Yes
Energy Saving Product	Yes
Approval Marks	RoHS compliance

Product Data

EAN/UPC - Case	6922341971204
Numerator - Quantity Per Pack	1
Order code	929003545709
Full product code	692234197119800
Order product name	LED MOD 24W 865
Full product name	LED MOD 24W 865
Material number (12NC)	929003545709
Numerator - Packs per outer box	20

Controls and Dimming

Dimmable

No

Mechanical and Housing

Bulb Finish	Clear
Bulb Shape	Others
Product Length	200 mm
Bulb Material	Plastic

General Information

Lighting Technology	LED
Switching Cycle	20,000
Cap-Base	-  [-]
Nominal lifetime	20,000 hour(s)

Temperature

T-Case Maximum (Nom)	75 °C
Ambient temperature range	-20 °C to 45 °C

Light Technical

Luminous Flux	3,000 lumen
LLMF At End Of Nominal Lifetime (Nom)	70 %
Color Designation	Cool Daylight
Correlated Color Temperature (Nom)	6500 K
Color Consistency	<6
Color rendering index (CRI)	80
Beam Angle (Nom)	120 degree(s)
Color Code	865  [CCT of 6500K]
Luminous Efficacy (rated) (Nom)	125 lm/W
