16.5T8/MAS/48-850/MF25/P/DIM 25/1

Specifications Show all

Operating and Electrical

Line Frequency	50 to 60 Hz
Input Frequency	50 to 60 Hz
Warm-up time to 60% light	0.5 s
Power Consumption	16.5 W
Voltage (Nom)	120-277 V
Power Factor (Fraction)	0.9
Starting Time (Nom)	0.5 s

Product Data

EAN/UPC - Case	50046677579536
Numerator - Quantity Per Pack	1
Order product name	16.5T8/MAS/48-850/MF25/P/DIM 25/1
Order code	929003526004
Full product name	16.5T8/MAS/48-850/MF25/P/DIM 25/1
Material number (12NC)	929003526004
Numerator - Packs per outer box	25

Approval and Application

EU RoHS compliant	Yes
Energy Saving Product	Yes
Approval Marks	RoHS compliance	UL certificate	DLC compliance

Controls and Dimming

Dimmable

Only with specific dimmers

Mechanical and Housing

Bulb Finish	Frosted
Bulb Shape	Tube, double-ended
Product Length	1,200 mm
Bulb Material	Plastic

General Information

Lighting Technology	LED
Switching Cycle	50,000
Cap-Base	G13  [Medium Bi-Pin Fluorescent]
Nominal lifetime	70,000 hour(s)

Temperature

T-Case Maximum (Nom)	70 °C
Ambient temperature range	-20 °C to 45 °C

Light Technical

Luminous Flux	2,500 lumen
LLMF At End Of Nominal Lifetime (Nom)	70 %
Color Designation	Daylight
Correlated Color Temperature (Nom)	5000 K
Luminous Efficacy (rated) (Nom)	151.00 lm/W
Color Consistency	<5
Color rendering index (CRI)	80
Beam Angle (Nom)	180 degree(s)
Color Code	850  [CCT of 5000K]
