    • The affordable LEDTube T8 solution

      Ledtube DE 1200mm 18W 765 T8 G13 RCA
      LED
      Ledtube DE 1200mm 18W 765 T8 G13 RCA
      Ecofit Ledtubes T8

      Ledtube DE 1200mm 18W 765 T8 G13 RCA

      Order code: 929002375437

      Full Product Code: 871951426106800

      Downloads

      Spec Sheet
      Size:692.0 kB

      See all downloads

    Specifications Show all

    General Information
    Cap-Base
    G13  [ Medium Bi-Pin Fluorescent]
    EU RoHS compliant
    Yes
    Nominal Lifetime (Nom)
    15000 h
    Switching Cycle
    50000X
    Technical Type
    18-36W
    Light Technical
    Color Code
    765  [ CCT of 6500K]
    Beam Angle (Nom)
    240 °
    Luminous Flux (Nom)
    1800 lm
    Color Designation
    Cool Daylight
    Correlated Color Temperature (Nom)
    6500 K
    Luminous Efficacy (rated) (Nom)
    100.00 lm/W
    Color Consistency
    <7
    Color Rendering Index (Nom)
    70
    LLMF At End Of Nominal Lifetime (Nom)
    70 %
    Operating and Electrical
    Input Frequency
    50 to 60 Hz
    Power (Nom)
    18 W
    Lamp Current (Nom)
    155 mA
    Starting Time (Nom)
    0.5 s
    Warm Up Time to 60% Light (Nom)
    0.5 s
    Power Factor (Nom)
    0.5
    Voltage (Nom)
    220-240 V
    Temperature
    T-Ambient (Max)
    45 °C
    T-Ambient (Min)
    -20 °C
    T-Storage (Max)
    65 °C
    T-Storage (Min)
    -40 °C
    T-Case Maximum (Nom)
    60 °C
    Controls and Dimming
    Dimmable
    No
    Mechanical and Housing
    Product Length
    1200 mm
    Bulb Shape
    Tube, double-ended
    Approval and Application
    Energy Saving Product
    Yes
    Approval Marks
    RoHS compliance
    KEMA Keur certificate
    Energy Consumption kWh/1000 h
    18 kWh
    Product Data
    Full product code
    871951426106800
    Order product name
    Ledtube DE 1200mm 18W 765 T8 G13 RCA
    EAN/UPC - Product
    8719514261068
    Order code
    929002375437
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    20
    Material Nr. (12NC)
    929002375437
    Net Weight (Piece)
    0.225 kg

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
     Medium Bi-Pin Fluorescent Tube, double-ended
    Medium Bi-Pin Fluorescent Tube, double-ended
    G13
    G13
    Performance Diagrams
    LEDtube 18W 15K LumenVsTc
    LEDtube 18W 15K LumenVsTc
    LEDtube 15K
    LEDtube 15K
    LEDtube 15K FailureRate
    LEDtube 15K FailureRate
    LEDtube 15K
    LEDtube 15K
    LEDtube 15K LifetimeVsTc
    LEDtube 15K LifetimeVsTc
    Photometrics
    LEDtube 18W G13 1800lm 765
    LEDtube 18W G13 1800lm 765
    LEDtube 16W G13 765 CN I G
    LEDtube 16W G13 765 CN I G
    LEDtube 18W G13 1800lm
    LEDtube 18W G13 1800lm
    Downloads
    Leaflets
    Green Data
    Visuals
    Software Plugins
    • IES LEDtube 18W G13 1800lm 765 IES 18.0 kB
