| Inrush current | 4.6
A
|
| Input Voltage | 220-240
V
|
| Line Frequency | 50 to 60
Hz
|
| Power Consumption | 40
W
|
| Number of products on MCB of 16 A type B | 24
|
| Inrush time | 750
ms
|
| Connection | -
|
| Power Factor (Fraction) | 0.9
|
| Cable | Cable 0.75 m without plug
|
| Input Frequency | 50 to 60
Hz
|
| Lumen maintenance at median useful life* 50000 h | L70
|
| Control gear failure rate at median useful life 50000 h | 5
%
|
| EU RoHS compliant | Yes
|
| Flammability mark | For mounting on easily flammable surfaces
|
| Protection class IEC | Safety class II
|
| Ingress protection code | IP54
[Dust accumulation-protected, splash-proof] |
| Warranty period | 5 years
|
| Mech. impact protection code | IK03
[0.3 J] |
| CE mark | Yes
|
| ENEC mark | -
|
| Sustainability rating | -
|
| Glow-wire test | Temperature 650 °C, duration 30 s
|
| EAN/UPC - Case | 8718696072943
|
| Numerator - Quantity Per Pack | 1
|
| Order code | 910503910178
|
| Full product code | 871869607294300
|
| Full product name | CR150B LED35S/840 PSD W30L120 IP54
|
| EAN/UPC - Product | 8718696072943
|
| Material number (12NC) | 910503910178
|
| Numerator - Packs per outer box | 1
|
| Order product name | CR150B LED35S/840 PSD W30L120 IP54
|
| Driver/power unit/transformer | Power supply unit with DALI interface
|
| Constant light output | No
|
| Control interface | DALI
|
| Dimmable | Yes
|
| Light source replaceable | Yes
|
| Value ladder | Performance
|
| Lamp family code | GRN35
[LED GreenLine 3500 lm] |
| Driver included | Yes
|
| Number of gear units | 1 unit
|
| Remarks | *-Per Lighting Europe guidance paper “Evaluating performance of LED based luminaires - January 2018”: statistically there is no relevant difference in lumen maintenance between B50 and for example B10. Therefore, the median useful life (B50) value also represents the B10 value.
|
| Lighting Technology | LED
|
| Overall length | 1,195
mm
|
| Reflector material | -
|
| Optic material | -
|
| Overall width | 295
mm
|
| Optical cover/lens material | Polymethyl methacrylate
|
| Dimensions (Height x Width x Depth) | 86 x 295 x 1195 mm
|
| Housing Color | White
|
| Optical cover/lens finish | Opal
|
| Fixation material | -
|
| Housing Material | Steel
|
| Overall height | 86
mm
|
| Suitable for random switching | Yes
|
| Maximum dim level | 1%
|
| Performance ambient temperature Tq | 25 °C
|
| Initial chromaticity | (0.38, 0.38) SDCM <4
|
| Luminous flux tolerance | +/-5%
|
| Power consumption tolerance | +/-5%
|
| Ambient temperature range | 0 to +40 °C
|
| Luminous Flux | 3,500
lumen
|
| Correlated Color Temperature (Nom) | 4000
K
|
| Number of light sources | 2
|
| Optic type | -
|
| Unified glare rating CEN | Not applicable
|
| Luminaire light beam spread | 110°
|
| Color rendering index (CRI) | >80
|
| Luminous Efficacy (rated) (Nom) | 88
lm/W
|
| Light source color | 840 neutral white
|
| Optical cover/lens type | Polymethyl methacrylate bowl/cover
|
