MHC70/C/U/M/4K ELITE

Specifications Show all

General Information

Cap-Base	E26  [ Single Contact Medium Screw]
Operating Position	UNIVERSAL  [ Any or Universal (U)]
Main Application	General Lighting (G)
Life to 50% Failures (Nom)	20000 h
ANSI Code HID	C98/E
Features	ELITE

Light Technical

Color Code	842  [ CCT of 4200K]
Luminous Flux (Rated) (Min)	5600 lm
Luminous Flux (Rated) (Nom)	6200 lm
Color Designation	Cool White (CW)
Lumen Maintenance - 40% Life	80 %
Lumen Maintenance - 10% Life	90 %
Design Mean Lumens	4960 lm
Chromaticity Coordinate X (Max)	0.379
Chromaticity Coordinate X (Min)	0.361
Chromaticity Coordinate X (Nom)	0.370
Chromaticity Coordinate Y (Max)	0.368
Chromaticity Coordinate Y (Min)	0.356
Chromaticity Coordinate Y (Nom)	0.362
Correlated Color Temperature (Nom)	4200 K
Luminous Efficacy (Rated) (Min)	84 lm/W
Luminous Efficacy (rated) (Nom)	89 lm/W
Color Rendering Index (Min)	85
Color Rendering Index (Nom)	88

Operating and Electrical

Lamp Current (Nom)	0.91 A
Ignition Supply Voltage (Min)	250 V
Re-Ignition Time (Min) (Max)	8 min
Ignition Time (Max)	30 s
Voltage (Max)	110 V
Voltage (Min)	90 V
Voltage (Nom)	95 V

Mechanical and Housing

Bulb Finish	Coated glass
Cap-Base Information	Brass Cap
Bulb Material	Hard Glass

Approval and Application

Picogram Per Lumen Hour	76 pg/lm.h
Mercury (Hg) Content (Max)	7.1 mg

UV

Pet (Niosh) (Nom)	95 h/500lx
Damage Factor D/fc (Nom)	0.6

Luminaire Design Requirements

Bulb Temperature (Max)	400 °C
Cap-Base Temperature (Max)	190 °C

Product Data

Order product name	MHC70/C/U/M/4K ELITE
EAN/UPC - Product	046677429911
Order code	928601177501
Numerator - Quantity Per Pack	1
Numerator - Packs per outer box	12
Material Nr. (12NC)	928601177501
Net Weight (Piece)	0.001 kg
